Thermo Scientific - Particle Size Analyzer PSM-500

Supplier: Thermo Fisher Scientific

Particle Size Analyzer PSM-500

The Particle Size Analyzer PSM-500 provides real-time, in-stream analysis of particle size, improving mineral processing efficiency and quality in demanding environments.

Provides real-time, highly accurate in-stream particle size analysis for effective process optimisation.

The PSM-500 is a rugged, on-line particle size analyser designed for continuous real-time monitoring and optimisation of grinding circuit performance. Utilising advanced ultrasonic technology, it delivers accurate particle size data for up to three sample streams, supporting energy efficiency and mineral recovery.

Key Features

Real-time in-stream particle analysis of up to three streams.
Rugged construction - IP65 ingress protection and NEMA 4X corrosion resistance.
Contemporary user interface with full-colour, intuitive local touch-panel.
Field-replaceable, high bandwidth transducers for minimal downtime.
No dilution or pumping required.
Automatic % solids measurement as standard.
Rapid measurement update time (typically every 10 seconds).
No UPS needed, high system availability.
Upgradeable from PSM-400MPX models.

Benefits

Enhances mineral recovery by providing accurate particle size distribution and percent solids analysis.
Improves energy efficiency and throughput in grinding control.
Designed for extreme environments with temperature compensation and a wide operational range.
Easy calibration through the modern interface and control systems.
Lower maintenance and cost of ownership due to field-replaceable transducers.

Specifications

Sample Streams	Up to 3
Particle Size Range	1 to 1000 microns (optimisable per application)
Accuracy	Typically <1% absolute
Update Time	Typically 10 seconds
Solids Content (% by Weight)	10% Min – 60% Max
Solids Content (% by Volume)	3% Min – 26% Max
Density (dry solids)	2.0 to 5.5 SG
Sample Diameter	Max <2.3 mm @ <1% retained by Wt. @ 2.7 SG, Max <1.2 mm @ <1% retained by Wt. @ 5.1 SG
Chemical Compatibility	Caustic slurries up to pH 12.5
Operating Temperature	Ambient -10°C to +50°C
Operating Altitude	0 to 5000 metres
Electrical Requirements	380/600 V, 50/60 Hz, 3-phase
Electronics Housing	IP65; CE; ICES 001, CSA, FCC Part 15B, RCM
Sample Water for Measurement	Min. Pressure: 276 kPa, Max. Pressure: 689 kPa, Flow: 45 L/min.
Ambient Environment	No direct sunlight/UV, not for unprotected outdoor use
Material (Wetted Parts)	Engineering polymers or rubber-covered steel
Quality Assurance	Adelaide manufacturing facility, ISO-9001:2000 certified
Surface Coating	Commercial sandblast, polyurethane fill primer, two-part epoxy colour finish
Vibration Tolerance	Up to 10G at 20Hz
Unit Size	Each

To contact Thermo Fisher Scientific about Thermo Scientific Particle Size Analyzer PSM-500 use Get a quote.
