Merlo MF44.9CS Agricultural Telehandler

Merlo - MF44.9CS Agricultural Telehandler

Supplier: Sydney Trucks & Machinery STM

Merlo - MF44.9CS Agricultural Telehandler

MF44.9CS Agricultural Telehandler

Merlo - MF44.9CS Agricultural Telehandler

The MF44.9CS Telehandler is a high-performance machine designed to handle heavy loads with precision and reliability for agricultural and material lifting tasks.

High lifting capacity and reach with advanced stability control.

Performance & Features

Total unladen weight: 9050 kg
Maximum capacity: 4000 kg
Lifting height: 8.9 m
Maximum reach: 6.1 m
Maximum operating height: 7.7 m
Maximum operating reach: 1.7 m
Capacity at maximum height: 3000 kg
Capacity at maximum reach: 900 kg
Lateral boom movement: ± 8%
Boom sections: 3

Powertrain

Engine: FPT NEF45 Turbo Motor
Displacement/Cylinders: 4500 cc / 4 cylinders
Engine Power: 125 kW / 170 HP
Anti-pollution technology: TIER 2
Reversible fan: Optional
Maximum speed: 40 km/h
Fuel tank: 150 L
Hydrostatic transmission: CVTronic
EPD, Auto-revving joystick
Axles - Reducers: Axial, Epicyclic
Brakes: Dry discs, Automatic parking brake

Hydraulics

Hydraulic pump flow rate/pressure: 150-210 l/min – 96 bar
Hydraulic tank: Not specified
Hydraulic outlet at top of boom / rear hydraulic outlets: 4+ (Premium)

Cab

ASCS Adaptive Stability Control System
FOPS LIV II & ROPS cab
Premium configuration, Full commands
Tilt cab, Boom and Cab suspension
Reverse shuttle, Cab suspension
Work headlights, Sun blind, Tac-lock, Platform provision
Two floating forks
Inching-Control, Four-wheel drive
Four-wheel steering, Three steering modes

Tyres & Stabilisers

Standard tyres: 500/70-R24
Optional tyres: 500/70 R24, 600/55-26.5, 500/70 R22.5
Stabilisers: Included

Approvals

Type approval as an agricultural tractor
Approval with pneumatic & hydraulic braking
PTO & 3-point linkage: Optional

Dimensions

Length (A)	5570 mm
Width (B)	1340 mm
Height (C)	2950 mm
Wheelbase (D)	1280 mm
Track width (E)	4270 mm
Ground clearance (F)	440 mm
Cab height (H)	2400 mm
Overall width (M)	1010 mm
Overall height (P)	2590 mm
Turning radius (R)	4090 mm
Overall length (S)	5020 mm
Platform width (Z)	850 mm

To contact Sydney Trucks & Machinery STM about Merlo MF44.9CS Agricultural Telehandler use Get a quote.

Performance & Features

Total unladen weight: 9050 kg
Maximum capacity: 4000 kg
Lifting height: 8.9 m
Maximum reach: 6.1 m
Maximum operating height: 7.7 m
Maximum operating reach: 1.7 m
Capacity at maximum height: 3000 kg
Capacity at maximum reach: 900 kg
Lateral boom movement: ± 8%
Boom sections: 3

Powertrain

Engine: FPT NEF45 Turbo Motor
Displacement/Cylinders: 4500 cc / 4 cylinders
Engine Power: 125 kW / 170 HP
Anti-pollution technology: TIER 2
Reversible fan: Optional
Maximum speed: 40 km/h
Fuel tank: 150 L
Hydrostatic transmission: CVTronic
EPD, Auto-revving joystick
Axles - Reducers: Axial, Epicyclic
Brakes: Dry discs, Automatic parking brake

Hydraulics

Hydraulic pump flow rate/pressure: 150-210 l/min – 96 bar
Hydraulic tank: Not specified
Hydraulic outlet at top of boom / rear hydraulic outlets: 4+ (Premium)

Cab

ASCS Adaptive Stability Control System
FOPS LIV II & ROPS cab
Premium configuration, Full commands
Tilt cab, Boom and Cab suspension
Reverse shuttle, Cab suspension
Work headlights, Sun blind, Tac-lock, Platform provision
Two floating forks
Inching-Control, Four-wheel drive
Four-wheel steering, Three steering modes

Tyres & Stabilisers

Standard tyres: 500/70-R24
Optional tyres: 500/70 R24, 600/55-26.5, 500/70 R22.5
Stabilisers: Included

Approvals

Type approval as an agricultural tractor
Approval with pneumatic & hydraulic braking
PTO & 3-point linkage: Optional

Dimensions

Length (A)	5570 mm
Width (B)	1340 mm
Height (C)	2950 mm
Wheelbase (D)	1280 mm
Track width (E)	4270 mm
Ground clearance (F)	440 mm
Cab height (H)	2400 mm
Overall width (M)	1010 mm
Overall height (P)	2590 mm
Turning radius (R)	4090 mm
Overall length (S)	5020 mm
Platform width (Z)	850 mm

To contact Sydney Trucks & Machinery STM about Merlo MF44.9CS Agricultural Telehandler use Get a quote.
