Snorkel - TM12E Electric Telescopic Mast Lift

Supplier: Equipment Sales Australia

TM12E Electric Telescopic Mast Lift

The TM12E Electric Telescopic Mast Lift is designed for safe and efficient elevated work, offering compact dimensions and electric drive for easy manoeuvrability indoors and out.

Electric drive system with zero inside turning radius for superior indoor manoeuvrability.

Main Features

Electric drive system for longer duty cycles and zero inside turning radius
Lifts up to 227kg to a platform height of 3.65m (max working height: 5.65m)
Integrated power to platform outlet and upper control box
Roll-out deck extension and proportional controls
Saloon-door style entry gates, descent and tilt alarms
Non-marking rubber tyres and emergency lowering at chassis controls
Suitable for 2 persons indoor or 1 person outdoor
Selectable motion alarm, horn, hour meter and on-board diagnostics display
Integrated 24V 220Ah battery system with 20A charger
2-year parts & labour, 5-year structural warranty

Specifications

Max Working Height	5.65 m
Max Platform Height	3.65 m
Platform Size (Stowed)	0.68 m x 0.99 m
Platform Size (Extended)	0.68 m x 1.5 m
Extension Deck Length	0.51 m
Overall Width	0.76 m
Overall Length	1.37 m
Stowed Height	1.7 m
Ground Clearance	76 mm
Platform Capacity (SWL)	227 kg
Max Drive Height	3.65 m
Max Wind Speed	12.5 m/s
Max Drive Speed (Stowed)	4.0 km/h
Max Drive Speed (Elevated)	0.6 km/h
Raise/Lower Time	12.5 / 10.5 sec
Gradeability	25%
Max Operating Slope (Side to Side)	2°
Max Operating Slope (Front to Back)	2°
Inside Turning Radius	0 m
Outside Turning Radius	1.4 m
Tyres	323 mm Non-marking rubber
Parking Brake	2 wheel, spring applied, electric release
Drive System	Dual DC motors
Controls	Proportional
Power Source	24V 220Ah batteries
Battery Charger	20 amp
Weight	1,016 kg

Additional Information

Crane lift points for easy transport and installation
Comprehensive network of service providers supports after-sales care
Expert advice and reliable brands from Equipment Sales Australia

To contact Equipment Sales Australia about Snorkel TM12E Electric Telescopic Mast Lift use Get a quote.

Main Features

Electric drive system for longer duty cycles and zero inside turning radius
Lifts up to 227kg to a platform height of 3.65m (max working height: 5.65m)
Integrated power to platform outlet and upper control box
Roll-out deck extension and proportional controls
Saloon-door style entry gates, descent and tilt alarms
Non-marking rubber tyres and emergency lowering at chassis controls
Suitable for 2 persons indoor or 1 person outdoor
Selectable motion alarm, horn, hour meter and on-board diagnostics display
Integrated 24V 220Ah battery system with 20A charger
2-year parts & labour, 5-year structural warranty

Specifications

Max Working Height	5.65 m
Max Platform Height	3.65 m
Platform Size (Stowed)	0.68 m x 0.99 m
Platform Size (Extended)	0.68 m x 1.5 m
Extension Deck Length	0.51 m
Overall Width	0.76 m
Overall Length	1.37 m
Stowed Height	1.7 m
Ground Clearance	76 mm
Platform Capacity (SWL)	227 kg
Max Drive Height	3.65 m
Max Wind Speed	12.5 m/s
Max Drive Speed (Stowed)	4.0 km/h
Max Drive Speed (Elevated)	0.6 km/h
Raise/Lower Time	12.5 / 10.5 sec
Gradeability	25%
Max Operating Slope (Side to Side)	2°
Max Operating Slope (Front to Back)	2°
Inside Turning Radius	0 m
Outside Turning Radius	1.4 m
Tyres	323 mm Non-marking rubber
Parking Brake	2 wheel, spring applied, electric release
Drive System	Dual DC motors
Controls	Proportional
Power Source	24V 220Ah batteries
Battery Charger	20 amp
Weight	1,016 kg

Additional Information

Crane lift points for easy transport and installation
Comprehensive network of service providers supports after-sales care
Expert advice and reliable brands from Equipment Sales Australia

Read less...

To contact Equipment Sales Australia about Snorkel TM12E Electric Telescopic Mast Lift use Get a quote.
