Focus - Aluminum Filter Housing | 46-1270 Cfm (1303-35962 L/Min)

Supplier: Focus Air Compressor Solutions

Aluminum Filter Housing | 46-1270 Cfm (1303-35962 L/Min)

Clean, Reliable, Compressed Air for Any Application

In Stock

Airborne particles, water vapour, microbes and chemical gases enter compressors.

After compression has taken place these contaminants become concentrated and more destructive.

Air Filters remove these contaminants, giving you instrument quality air.

16bar (232 psi) Operating Pressure
0.005-1 Micron Particulate Removal
0.008-04 ppm Max Oil Carry Over
1.6-65°C Operating Temperature
Indiviual Filter Elements are available
Optional Differential Pressure Gauge

Specifications and Extras

UTILITY GRADE COALESCING

General Compressed Air Filtration
99.99% Efficiency
Particulate removal down to 1 micron
Max oil carry over 0.4ppm w/w
Nominal pressure drop 0.75psi
ISO 8573 (Class 2)

Complete Unit	Mircon	Element No.
FHO-4150	1	9060105
FHO80135	1	9060135
FHO-200195	1	9060195
FHO-460225	1	9060225
FHO-885305	1	9060305
FHO-100330	1	9060330
FHO-1625380	1	9060380

HIGH EFFICIENCY COALESCING

High Quality Compressed Air Filtration
99.99% Efficiency
Particulate removal down to 0.01 mircon
Max oil carry over 0.008ppm w/w
Nominal pressure drop 0.5psi
ISO 8573 (Class 1)

Complete Unit	Mircon	Element No.
FHO-45110	0.01	9060110
FHO-80140	0.01	9060140
FHO-200200	0.01	9060200
FHO-460260	0.01	9060260
FHO-885310	0.01	9060310
FHO-1000335	0.01	9060335
FHO-1625385	0.01	9060385

ACTIVATED CARBON

High purity extended surface area
Activated carbon removes hydrocarbon mist and vapor
Max oil carry over 0.02ppm w/w
Nominal pressure drop 1.2psi
Particulate removal down to 0.005 micron

Complete Unit	Mircon	Element No.
FHO-45085	0.005	9060085
FHO-80115	0.005	9060115
FHO-200175	0.005	9060175
FHO-4060235	0.005	9060235
FHO-885290	0.005	9060290
FHO-1000315	0.005	9060315
FHO-1625365	0.005	9060365

To contact Focus Air Compressor Solutions about Focus Aluminum Filter Housing | 46-1270 Cfm (1303-35962 L/Min) use Get a quote.

Airborne particles, water vapour, microbes and chemical gases enter compressors.

After compression has taken place these contaminants become concentrated and more destructive.

Air Filters remove these contaminants, giving you instrument quality air.

16bar (232 psi) Operating Pressure
0.005-1 Micron Particulate Removal
0.008-04 ppm Max Oil Carry Over
1.6-65°C Operating Temperature
Indiviual Filter Elements are available
Optional Differential Pressure Gauge

Specifications and Extras

UTILITY GRADE COALESCING

General Compressed Air Filtration
99.99% Efficiency
Particulate removal down to 1 micron
Max oil carry over 0.4ppm w/w
Nominal pressure drop 0.75psi
ISO 8573 (Class 2)

Complete Unit	Mircon	Element No.
FHO-4150	1	9060105
FHO80135	1	9060135
FHO-200195	1	9060195
FHO-460225	1	9060225
FHO-885305	1	9060305
FHO-100330	1	9060330
FHO-1625380	1	9060380

HIGH EFFICIENCY COALESCING

High Quality Compressed Air Filtration
99.99% Efficiency
Particulate removal down to 0.01 mircon
Max oil carry over 0.008ppm w/w
Nominal pressure drop 0.5psi
ISO 8573 (Class 1)

Complete Unit	Mircon	Element No.
FHO-45110	0.01	9060110
FHO-80140	0.01	9060140
FHO-200200	0.01	9060200
FHO-460260	0.01	9060260
FHO-885310	0.01	9060310
FHO-1000335	0.01	9060335
FHO-1625385	0.01	9060385

ACTIVATED CARBON

High purity extended surface area
Activated carbon removes hydrocarbon mist and vapor
Max oil carry over 0.02ppm w/w
Nominal pressure drop 1.2psi
Particulate removal down to 0.005 micron

Complete Unit	Mircon	Element No.
FHO-45085	0.005	9060085
FHO-80115	0.005	9060115
FHO-200175	0.005	9060175
FHO-4060235	0.005	9060235
FHO-885290	0.005	9060290
FHO-1000315	0.005	9060315
FHO-1625365	0.005	9060365
