Anton Paar - Handheld Alcohol Meter | Snap 41/51 Get latest price

Handheld Alcohol Meter | Snap 41/51

Handheld Alcohol Meter | Snap 41/51

Handheld Alcohol Meter | Snap 41/51

Handheld Alcohol Meter | Snap 41/51

One instrument covers 0% - 100% v/v

In Stock

Key features

• Accuracy: Snap 51 = 0.1 %v/v,  Snap 41 = 0.2%v/v.
• For on-site measurement at distilleries and craft distilleries

Alcohol measurement with easy procedures – no human errors

• Temperature correction of results is done automatically: no need for temperature correction tables
• Values are shown in %v/v (corrected to 20 °C )
• Fine-tune your spirit’s alcoholic strength with an accuracy of 0.1 %v/v (Snap 51) or 0.2 %v/v (Snap 41) and save valuable pure distilled spirits.
• Calibration and adjustments are easy to perform with deionized water, following the predefined routine.
• Snap 51 can identify samples via RFID for excellent traceability of results

Use the same portable alcohol meter along the whole production process

• Alcohol measuring range from 0 %v/v to 100 %v/v
• All your glass hydrometers are replaced by one digital alcohol hydrometer.
• You can use Snap 51 during all stages of spirits production.
• The sugar concentration in fruit juices can also be measured (Snap 51)
• If you already have an alcohol meter in your lab, use Snap 41/51 for additional quick checks during production or for intake control.

Perform your alcohol measurements on-site in 30 seconds

• 2 mL of sample are taken directly from the storage container with the help of the built-in pump.
• Convenient left- and right-handed use
• Measuring cell with inspection window and backlight for convenient inspection of proper sample filling. (Snap 41)
• Automatically rotating screen for conveniently readable results at any instrument position

An impressively long working life

• Robust measuring cell made of metal (Inconel - Snap 51) with a splash-proof housing and hard-glass front
• Operated via capacitive keys with a sensitivity suitable for use with or without gloves
• Designed for on-site use at the storage location of your spirits
• Special rubber protection for measuring cell included to absorb knocks during routine operation (Snap 41)

A high-class digital alcohol meter from the market leader

• The alcohol concentration is derived from a highly accurate density measurement based on the oscillating U-tube principle.
• Anton Paar is the market leader in this technology and has more than 50 years of experience.
• Digital alcohol meters from Anton Paar are the industry standard, used by large-scale distilleries, governmental organizations, and craft distilleries.

Technical specifications

	Snap 41	Snap 51
Patents granted	Patent AT516421 (B1), EP3015847 (B1)	–
Measuring range	Alcohol: 0 %v/v to 100 %v/v Temperature: 5 °C to 30 °C (41 °F to 86 °F) (automatic temperature correction)	Alcohol: 0 %v/v to 100 %v/v Temperature: 0 °C to 40 °C (32 °F to 104 °F) (automatic temperature correction)
Accuracy	Alcohol: 0.2 %v/v Temperature: 0.2 °C (0.4 °F)	Alcohol: 0.1 %v/v Temperature: 0.1 °C (0.2 °F)
Repeatability, s.d.*	Alcohol: 0.1 %v/v Temperature: 0.1 °C (0.2 °F)	Alcohol: 0.05 %v/v Temperature: 0.05 °C (0.1 °F)
Reproducibility, s.d.*	Alcohol: 0.15 %v/v	Alcohol: 0.07 %v/v
Resolution	Alcohol: 0.01 %v/v Temperature: 0.1 °C (0.1 °F)	Alcohol: 0.01 %v/v Temperature: 0.01 °C (0.01 °F)
Ambient temperature	0 °C to 35 °C (32 °F to 95 °F)	-10 °C to +50 °C (14 °F to 122 °F)
Measuring principle	Oscillating U-tube technology	Oscillating U-tube technology
Supported measuring units	Alcohol concentration in %v/v at 20 °C or at 15 °C, °Proof	Alcohol concentration in %v/v (at 20 °C or at 15 °C) or °Proof Density Sugar/extract concentration in °Brix or °Plato Ten programmable custom-specific measuring units
Internal Storage	–	1024 measured results, 250 sample IDs, 30 measuring methods
Power supply	Three 1.5 V LR06 AA alkaline batteries	Three 1.5 V LR06 AA alkaline batteries
Sample volume	2 mL	2 mL
Dimensions	245 mm x 103 mm x 126 mm (9.6 in x 4 in x 5 in)	468 mm x 108 mm x 119 mm (18.4 in x 4.3 in x 4.7 in)
Weight	660 g (23.3 ounces)	860 g (30.3 ounces)
Interfaces	Bluetooth® (for software update only)	Bluetooth® (data transfer to a PC or printer), RFID (sample identification)
Protection class	IP54	IP54
Optional available accessories	Wristband, rubber protection housing for the operating panel, transportation suitcase	Wristband, rubber protection housing for the operating panel, portable Bluetooth® printer, Bluetooth® USB adapter



Read more...

To contact Anton Paar Australia about Anton Paar Handheld Alcohol Meter | Snap 41/51 use Get a quote.

Key features

• Accuracy: Snap 51 = 0.1 %v/v,  Snap 41 = 0.2%v/v.
• For on-site measurement at distilleries and craft distilleries

Alcohol measurement with easy procedures – no human errors

• Temperature correction of results is done automatically: no need for temperature correction tables
• Values are shown in %v/v (corrected to 20 °C )
• Fine-tune your spirit’s alcoholic strength with an accuracy of 0.1 %v/v (Snap 51) or 0.2 %v/v (Snap 41) and save valuable pure distilled spirits.
• Calibration and adjustments are easy to perform with deionized water, following the predefined routine.
• Snap 51 can identify samples via RFID for excellent traceability of results

Use the same portable alcohol meter along the whole production process

• Alcohol measuring range from 0 %v/v to 100 %v/v
• All your glass hydrometers are replaced by one digital alcohol hydrometer.
• You can use Snap 51 during all stages of spirits production.
• The sugar concentration in fruit juices can also be measured (Snap 51)
• If you already have an alcohol meter in your lab, use Snap 41/51 for additional quick checks during production or for intake control.

Perform your alcohol measurements on-site in 30 seconds

• 2 mL of sample are taken directly from the storage container with the help of the built-in pump.
• Convenient left- and right-handed use
• Measuring cell with inspection window and backlight for convenient inspection of proper sample filling. (Snap 41)
• Automatically rotating screen for conveniently readable results at any instrument position

An impressively long working life

• Robust measuring cell made of metal (Inconel - Snap 51) with a splash-proof housing and hard-glass front
• Operated via capacitive keys with a sensitivity suitable for use with or without gloves
• Designed for on-site use at the storage location of your spirits
• Special rubber protection for measuring cell included to absorb knocks during routine operation (Snap 41)

A high-class digital alcohol meter from the market leader

• The alcohol concentration is derived from a highly accurate density measurement based on the oscillating U-tube principle.
• Anton Paar is the market leader in this technology and has more than 50 years of experience.
• Digital alcohol meters from Anton Paar are the industry standard, used by large-scale distilleries, governmental organizations, and craft distilleries.

Technical specifications

	Snap 41	Snap 51
Patents granted	Patent AT516421 (B1), EP3015847 (B1)	–
Measuring range	Alcohol: 0 %v/v to 100 %v/v Temperature: 5 °C to 30 °C (41 °F to 86 °F) (automatic temperature correction)	Alcohol: 0 %v/v to 100 %v/v Temperature: 0 °C to 40 °C (32 °F to 104 °F) (automatic temperature correction)
Accuracy	Alcohol: 0.2 %v/v Temperature: 0.2 °C (0.4 °F)	Alcohol: 0.1 %v/v Temperature: 0.1 °C (0.2 °F)
Repeatability, s.d.*	Alcohol: 0.1 %v/v Temperature: 0.1 °C (0.2 °F)	Alcohol: 0.05 %v/v Temperature: 0.05 °C (0.1 °F)
Reproducibility, s.d.*	Alcohol: 0.15 %v/v	Alcohol: 0.07 %v/v
Resolution	Alcohol: 0.01 %v/v Temperature: 0.1 °C (0.1 °F)	Alcohol: 0.01 %v/v Temperature: 0.01 °C (0.01 °F)
Ambient temperature	0 °C to 35 °C (32 °F to 95 °F)	-10 °C to +50 °C (14 °F to 122 °F)
Measuring principle	Oscillating U-tube technology	Oscillating U-tube technology
Supported measuring units	Alcohol concentration in %v/v at 20 °C or at 15 °C, °Proof	Alcohol concentration in %v/v (at 20 °C or at 15 °C) or °Proof Density Sugar/extract concentration in °Brix or °Plato Ten programmable custom-specific measuring units
Internal Storage	–	1024 measured results, 250 sample IDs, 30 measuring methods
Power supply	Three 1.5 V LR06 AA alkaline batteries	Three 1.5 V LR06 AA alkaline batteries
Sample volume	2 mL	2 mL
Dimensions	245 mm x 103 mm x 126 mm (9.6 in x 4 in x 5 in)	468 mm x 108 mm x 119 mm (18.4 in x 4.3 in x 4.7 in)
Weight	660 g (23.3 ounces)	860 g (30.3 ounces)
Interfaces	Bluetooth® (for software update only)	Bluetooth® (data transfer to a PC or printer), RFID (sample identification)
Protection class	IP54	IP54
Optional available accessories	Wristband, rubber protection housing for the operating panel, transportation suitcase	Wristband, rubber protection housing for the operating panel, portable Bluetooth® printer, Bluetooth® USB adapter



Read less...

To contact Anton Paar Australia about Anton Paar Handheld Alcohol Meter | Snap 41/51 use Get a quote.
