Stainless Steel Chain Link Fence Fabric

Stainless Steel Chain Link Fence Fabric

Stainless Steel Chain Link Fence Fabric

Stainless Steel Chain Link Fence Fabric

Stainless Steel Chain Link Fence Fabric

Chain link fence for New Zealand and Australia markets are manufactured using a variety of different wire types. Our chain wire mesh fencing, also known as cyclone wire fencing, is usually made from 2.50mm standard wire or 3.15mm wire. They can also be known as cyclone wire fencing. We have over 30 years experience with producing chain link fences in China.

Material

SS 304, SS 316 ETC.

Specifications:

Wire thickness	1.0mm-6.0mm
Mesh opening	20x20mm,50x50mm,60x60mm,80x80mm,100x100mm etc
Mesh height	0.5m-6m
Mesh length	4m-50m



Mesh	Stainless Steel 304, 316
	Wire BWG	Wire Dia.(mm)	Weight kg/m2		Roll Dia  4' ×50'(mm)
1'' (25mm)	12	2.8	3.81	15.5	220
	13	2.4	2.9	12.2	200
	14	2.1	2.3	9.75	180
	16	1.6	1.34	6.4	160
1.5'' (40mm)	10	3.4	3.7	14.6	280
	11	3.0	3	12.0	250
	12	2.8	2.4	10.0	230
	14	2.1	1.4	6.2	220
2'' (50mm)	8	4.2	4.5	18.4	280
	10	3.4	2.9	11.8	250
	12	2.8	1.9	8.0	230
	14	2.1	1.2	5.4	220
2.25'' (56mm)	8	4.2	3.9	14.8	290
	10	3.4	2.6	10.5	280
	12	2.8	1.7	7.3	250
	14	2.1	1.0	4.5	220
2.4'' (62.50mm)	8	4.2	3.7	14.3	290
	10	3.4	2.5	10.1	280
	12	2.8	1.63	6.8	250
	14	2.1	1.00	4.6	220
2.5'' (64mm)	8	4.2	3.5	14.8	290
	10	3.4	2.3	9.4	280
	12	2.8	1.6	6.5	250
	14	2.1	0.9	4.2	220
3'' (76mm)	8	4.2	3.00	11.7	300
	10	3.4	2.00	8.2	290
	12	2.8	1.3	5.7	280
	14	2.1	0.8	3.8	250

Weave Methods

We supply knuckled or Barb selvedge

1. Knuckle-knuckle
2. Barb-barb
3. Knuckle-barb

Applications:

• Commercial grounds
• Private grounds
• Road and transmit
• Used as fencing, decoration or protection for various facilities in industry, agriculture, transport etc.

Read more...

To contact Maishi Wire Mesh Manufacture Group about Stainless Steel Chain Link Fence Fabric use Get a quote.
