As a leading Steel Welded Wire Mesh supplier and manufacturer,Hebei Maishi offers a full range of welded wire mesh for various applications. We supply the mesh from 1/2" to 6", customer requests can be customized.
Welded wire mesh is generally constructed in rolls or flat panels designed by customers. Green plastic coating is widely used for fence and breeding. Custom wire openings available upon request.
Hebei Maishi Wire Mesh Group supply Galvanized Welded Wire Mesh with high quality, favorable price and excellent service.
Material
- Electro galvanized before welded wire mesh
- Electro galvanized after welded wire mesh
- Hot-dipped galvanized before welded wire mesh
- Hot-dipped galvanized after welded wire mesh
- Iron/galvanized wire+pvc coated
- Stainless steel 304,316 wire
Some customers ask the difference between before or after galvanized, please refer to the above image.
NOTE: We choose the best low carbon wire or stainless steel wire material available in China, and use the best plastic coating to guarantee the goods will have a long service life.
The high quality & reasonable price product is from the right material.
Specifications
| Opening |
Wire diameter |
Width |
| 1/4" x 1/4" |
0.5mm-0.7mm |
300mm-1828mm |
| 3/4" x 3/4" |
0.7mm-2.0mm |
300mm-1828mm |
| 3/8" x 3/8" |
0.7mm-1.1mm |
300mm-1828mm |
| 5/8" x 5/8" |
0.8mm-1.2mm |
300mm-1828mm |
| 1/2" x 1/2" |
0.45mm-1.6 mm |
300mm-1828mm |
| 1" x 1" |
0.7mm-3.0mm |
300mm-2000mm |
| 1" x 1/2" |
0.8mm-1.6mm |
300mm-1828mm |
| 1-1/2" x 1-1/2" |
0.7mm-3.5mm |
300mm-1828mm |
| 1" x 2" |
1.6mm-2.1mm |
300mm-1828mm |
| 2" x 2" |
0.7mm-4.0mm |
300mm-2500mm |
| 2" x 3" |
1.5mm-3.5mm |
300mm-2000mm |
| 2" x 4" |
2.0mm-4.0mm |
300mm-1828mm |
| 3" x 3" |
1.0mm-4.5mm |
300mm-2500mm |
| 3" x 4" |
1.5mm-4.5mm |
300mm-2000mm |
| 4" x 4" |
1.0mm-4.5mm |
300mm-2500mm |
| 5" x 5" |
2.5mm-4.5mm |
300mm-2500mm |
| 6" x 6" |
2.5mm-4.5mm |
300mm-2500mm |
Technical Note:
1. Standard roll length: 15.24m,30m,50m. 2. Special sizes available at request.
3. Packing: in waterproof paper in rolls. Custom packing available at request. |
| Welded Wire Mesh Panel |
| Mesh Size |
Wire diameter |
| In Inch |
In MM |
MM |
| 1/2" x 1/2" |
12.7mm |
1.0mm-2.0 mm |
| 1" x 1" |
25.4mm |
1.5mm-3.5mm |
| 1" 1/4" |
31.8mm |
2.0mm-4.0mm |
| 1 1/2" |
38.1mm |
2.0mm-5.0mm |
| 2" x 2" |
50.8mm |
2.0mm-6.0mm |
| 3" x 3" |
76.2mm |
3.0mm-7.0mm |
| 4" x 4" |
101.6mm |
3.0mm-8.0mm |
| 5" x 5" |
127.0mm |
4.0mm-9.0mm |
| 6" x 6" |
152.4mm |
4.0mm-10.0mm |
Panel Width & Length: 3Feet × 6Feet, 4Feet × 8Feet, 5Feet × 106Feet, 1M ×2M, 1.5M × 3M, 2M × 4M
Other panel sizes can also be made according to request. |
Production
Our automatic welding machines can set up any mesh sizes in the market, no matter if it is standard type or special requirement;
The fully digital controlled techniques and well-trained staff can ensure the even mesh size and the accurate dimensions of panels.
Application
- Guarding
- Railings
- Architectural
- Ceiling Tiles
- Partition Systems
- Farm
Guarantee
1. We guarantee our customers will get right material and sizes,enough weight,on time delivery at our best service and price
2. The goods can be returned or compensated if the quality is not ok
3. There is no "cheat" and "misunderstanding" in Maishi
Payment term
T/T (30%T/T paid in advance and 70% paid before shipment or against copy of BL), irrevocable L/C at sight, can be negotiable . .
Sample: Free sample can be sent on request.
Please call or email for a direct reply.
To serve you best we appreciate getting the following information :
1. Material: electro galvanized,hot dipped galvanized before or after welding if pvc coated(inner wire material)
2. Opening size
3. Wire diameter (if pvc coated before and after coated wire diameter)
4. Roll or pallets,sizes
5. Quantity
At your service all the time and welcome your inquiry. You are the reason why we are here.
Enterprise "quality, rapid, innovative, comprehensive and meticulous" business ideas;
Adhering to the "integrity, sound, professional''
