Chain Link Fence

Chain Link Fence

Chain Link Fence

Chain Link Fence

Specifications

Wire thickness	1.0mm-6.0mm
Mesh opening	20x20mm,50x50mm,60x60mm,80x80mm,100x100mm etc
Mesh height	0.5m-6m
Mesh length	4m-50m



Mesh	Hot Dipped					PVC Coated
	Wire BWG	Wire Dia.(mm)	Weight kg/m2		Roll Dia4' ×50'(mm)	Wire Dia. Before/after	Weight kg/m2		Roll Dia  4'×50'(mm)
1'' (25mm)	12	2.8	3.81	15.5	220	1.6/3.2	3.7	22.7	280
	13	2.4	2.9	12.2	200	2.0/2.6	2.3	15.4	240
	14	2.1	2.3	9.75	180	1.4/2.0	1.2	8.5	220
	16	1.6	1.34	6.4	160	1.0/1.6	0.7	507	200
1.5'' (40mm)	10	3.4	3.7	14.6	280	3.4/4.0	3.9	23.7	290
	11	3.0	3	12.0	250	2.6/3.2	2.4	14.7	280
	12	2.8	2.4	10.0	230	2.0/2.6	1.4	9.4	240
	14	2.1	1.4	6.2	220	1.4/2.0	0.8	5.5	220
2'' (50mm)	8	4.2	4.5	18.4	280	3.4/4.0	3.2	19.6	280
	10	3.4	2.9	11.8	250	2.6/3.2	1.9	12.2	250
	12	2.8	1.9	8.0	230	2.0/2.6	1.2	8.4	230
	14	2.1	1.2	5.4	220	1.4/2.0	0.6	4.4	220
2.25'' (56mm)	8	4.2	3.9	14.8	290	3.4/4.0	2.8	17	280
	10	3.4	2.6	10.5	280	2.6/3.2	1.7	10.8	250
	12	2.8	1.7	7.3	250	2.0/2.6	1.0	7.1	230
	14	2.1	1.0	4.5	220	1.4/2.0	0.55	4.3	220
2.4'' (62.50mm)	8	4.2	3.7	14.3	290	3.4/4.0	2.6	16.4	290
	10	3.4	2.5	10.1	280	2.6/3.2	1.6	10.6	280
	12	2.8	1.63	6.8	250	2.0/2.6	1.0	6.6	250
	14	2.1	1.00	4.6	220	1.4/2.0	0.48	3.85	230
2.5'' (64mm)	8	4.2	3.5	14.8	290	3.4/4.0	2.5	15.4	300
	10	3.4	2.3	9.4	280	2.6/3.2	1.5	9.8	280
	12	2.8	1.6	6.5	250	2.0/2.6	0.9	6.5	250
	14	2.1	0.9	4.2	220	/	/	/	/
3'' (76mm)	8	4.2	3.00	11.7	300	4.4/5.0	3.4	20.6	300
	10	3.4	2.00	8.2	290	3.4/4.0	2.1	13.0	280
	12	2.8	1.3	5.7	280	2.6/3.2	1.3	8.8	250
	14	2.1	0.8	3.8	250	/	/	/

Applications

• Commercial grounds
• Private grounds
• Road and transmit
• Used as fencing, decoration or protection for various facilities in industry, agriculture, transport etc.

Read more...

To contact Maishi Wire Mesh Manufacture Group about Chain Link Fence use Get a quote.
